Atomos SHINOBI II 5-inch 1500nit HDR Monitor - AOATOMSHB003

5-inch, 1500nit HDR monitor for vloggers, creatives and photographers

FEATURES

5-inch, 1500nit HDR monitor for vloggers, creatives and photographers
Much slimmer body and low-profile design – weighs just 210gms
50% brighter – 1500nit HDR, 5-inch, high-resolution touchscreen
Camera control via USB-C for Canon, Panasonic and Sony cameras, plus Z CAM cameras via optional USB-C to Serial cable
Use the Camera Status indicators to check the camera’s internal record settings, battery status & remaining record time
New AtomOS 11 user interface has a more modern look, more responsive operation and easy access to all the most-used monitoring tools
Powered by NP-F style batteries, or via USB-C PD (10W input). Also charge/power the camera via USB-C PD (13W output)
Included HDMI & USB-C locking adapter allows you to use Atomos' new line of locking cables for rock-solid connectivity
Unique Analysis Mode can deploy the waveform, histogram & vectorscope tools simultaneously
Frame Guides and 9 Grid help get perfect framing and composition
Low power consumption - Shinobi II can run all day off a single battery charge

Atomos has been developing amazing monitoring and recording technology for over a decade. Shinobi II has been redesigned with a new, slimline case and a 50% brighter HDR screen, yet it still manages to pack in all of Atomos' renowned screen processing technology and professional monitoring tools, plus exciting new hardware features like camera control. Take control of Canon, Panasonic or Sony cameras via USB-C, plus Z CAM cameras via optional USB-C to Serial cable. More vendors will be supported with future firmware releases. Due to its low power consumption and efficient hardware, Shinobi II will run all day on a single battery charge. Expose your shots accurately using our advanced exposure tools like false color, zebras, histograms, waveforms and vectorscopes. A multi-tool Analysis View gives you all the essential info at a glance. There’s even a selfie Mirror Mode for vloggers. Shinobi II is the perfect accessory to improve any photo or video production.

CAMERA CONTROL FOR AN EXTENSIVE LIST OF CAMERAS

Harnesses the versatility of USB-C to control most recent mirrorless or DSLR cameras from Canon, Panasonic and Sony, as well as the popular compact cinema cameras from Z CAM's E2 line. There are plans to support cameras from Fujifilm, Nikon, OM System and SIGMA with future firmware updates.

CHECK CAMERA STATUS AT A GLANCE

Use the Camera Status indicator to keep an eye on the camera’s internal record settings, battery status and remaining record time. The red edge display shows when the camera is recording internally, regardless of whether it's triggered by the camera or from the Shinobi II.

GET PERFECT EXPOSURE. EVERY TIME

Combine Shinobi II's ability to adjust your camera lenses' aperture, shutter speed/angle and ISO with its built-in exposure tools such as false color, waveforms, zebras, or the histogram and achieve perfect exposure on every shot.

NEW ATOMOS. NEW LOOK. NEW POSSIBILITIES

Shinobi II runs under a version of our latest operating system, AtomOS 11. It not only looks amazing, but introduces a host of great new features.

We’ve made the tools more visible and improved the look of the icons so you know exactly what you’re selecting. It’s easier to use, more logical and feels more professional.

OVERCOME THE LIMITATIONS OF SMALL CAMERA DISPLAYS

Enjoy the 50% brighter – 1500nit peak brightness, 5-inch, high-resolution HDR touchscreen, no matter if you're shooting in the studio or in bright sunlight.

MONITOR A VARIETY OF INPUT SIGNALS

Shinobi II comes equipped with a single HDMI 1.4 port and allows you to monitor signals in various resolutions and frame rates. Most notably, 4K DCI and 4K UHD at up to 30p, and 1080p HD signals at up to 60p.

HDR MONITORING AND LUT SUPPORT

Use the HDR HLG and HDR PQ monitoring modes to preview what your camera's LOG output might look like in HDR, or upload up to 8 LUTs to Shinobi's built-in storage to preview your shots in your favorite looks.

FRAME GUIDES FOR EVERY DELIVERY MEDIUM

Use a variety of cinema-style or social media-focused frame guides to compose your shots for every delivery medium. Shinobi II comes packed with presets for 2.41, 2.35, 1.91, 1.9, 1.85, 16:9, 9:16, 4:5, 2:3, 1:1, 5:4, 4:3, 3:2.

LIGHTWEIGHT AND ADAPTABLE

Despite adding even more hardware features, we managed to keep Shinobi II's weight down to an incredible 210 grams and added holes for locating pins at the bottom for more secure mounting in any situation. The battery compartment is placed at the center of the device to improve balancing and maneuverability, while the included HDMI & USB-C locking adapter allows you to use Atomos' new line of locking cables for rock-solid connectivity.

FLEXIBLE POWER OPTIONS

Power Shinobi II with NP-F style batteries, the optional battery eliminator in combination with our DC barrel to D-Tap cable, or via USB-C PD (10W input). You can also charge / power your camera via USB-C PD (13W output), all while using Shinobi II's camera control features.

SPECIFICATIONS

DISPLAY
Touchscreen	SuperAtom IPS panel (capacitive touch)
Size	5.2-inch
Resolution	1920 x 1080 178 + H & V
PPI	427
Bit depth	10-bit (8+2 FRC)
Backlight Type	Edge lit
Brightness (cdm2 / Nits)	1500
Aspect ratio	16/9
Colour Gamut	Rec.709
Calibration support	Atomos Calibrator on PC/Mac with Calibrite ColourChecker Display Pro & ColourChecker Display Plus and Simple on-device calibration (connect Calibrite probe directly to Shinobi II via USB-C)
COLOUR PIPELINE
Gamma	Sony SLog / SLog2 / SLog3 / HLG, Canon C-Log / C-Log2 / C-Log3, Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic V-Log / HLG, JVC J-Log, Red RedLogFilm / Log3G10 / Log3G12, FujiFilm F-Log, PQ (HDR10), HLG, Nikon N-Log
Gamut	BT.2020, DCI P3, DCI-P3 D65, Rec709, Sony S-Gamut / S-Gamut3 / S-Gamut3.cine / BT.2020 / Rec.709 Canon Cinema / BT.2020 / DCI P3 / DCI P3plus / Rec.709 Panasonic V Gamut / Rec.709 Arri Alexa Wide Gamut / Rec.709 JVC LS300 / Rec.709 Red DragonColour / DragonColour2 / RedColour2 / RedColour3 / RedColour4 / RedWideGamut
3D LUT Display	.Cube Format (17 & 33 points supported)
3DLUT 50/50	Yes
Monitoring Modes	SDR Native, HDR HLG, HDR PQ, 709 LUT, User LUT
VIDEO INPUT
HDMI	1 x HDMI (1.4)
Bit Depth	8/10-bit video
Video Chroma Subsampling	4:2:2
AUDIO IN/OUT
HDMI	2 channel, 24-bit, input dependent
Analogue Audio in	3.5mm headphone jack, 2 channel
Headphone out	3.5mm headphone jack, 2 channel
TIMECODE / SYNC / CONTROL
Embedded	HDMI (display only)
RESOLUTION & FRAME RATES (MONITOR)
4K DCI	23.98/24/25/29.97/30
4K UHD	23.98/24/25/29.97/30
FHD 1920 x 1080 Progressive	23.98/24/25/29.97/30/50/59.94/60
FHD 1920 x 1080 Interlaced	50i/60i
1280 x 720p	50/59.94/60p
SUPPORTED MEDIA
SD	Update firmware & upload LUTs
File System	FAT32, NTFS
ON SCREEN TOOLS
MultiScope Analysis View	Image, WFM, vector, histogram
Waveform	3 sizes – adjustable opacity & brightness
Histogram	3 sizes – adjustable opacity & brightness
RGB parade	3 sizes – adjustable opacity & brightness
Vector scope	1 size – adjustable opacity & brightness
1 x Zoom	Tap to zoom
2 x Zoom	Tap to zoom
4 x Zoom	Tap to zoom
Focus peaking	4 modes (colour, black & white, outline, edge sharpening) with adjustable outline colour & peaking intensity
Atomos False colour	Yes, with Scale
Zebra	Adjustable threshold (50% to 105%)
Isolate colour channel	Blue Only
Cine Frame Guides	Presets for 2.41, 2.35, 1.91, 1.9, 1.85, 16:9
Social Frame guides	Presets for 9:16, 4:5, 2:3, 1:1, 5:4, 4:3, 3:2
Safe areas	SMPTE safe title area – 93% & 90%
Grid markers	9 grid
Anamorphic desqueeze	2x, 1.8x, 1.79x, 1.65x, 1.6x, 1.5x, 1.33x, 1.25x
Display Flip	Horizontal & vertical
REMOTE CONTROL
Serial 2.5mm Jack	Calibration via optional USB to serial cable
EXTERNAL DEVICE CONTROL
Serial 2.5mm Jack	Camera control for Z CAM cameras via optional USB to Serial Cable
USB	Camera control for supported cameras via USB-C. Controllable functions: Record Trigger, White Balance, Shutter Speed, Shutter Angle (if supported by camera), Aperture, ISO, Camera Overlays, Record Indicator
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D mm)	151mm x 91.5mm x 20.8mm (28.5mm with locking cable adaptor attached)
Weight	210g / 7.4 oz
Mount points	Bottom: 1 x 1/4-inch 20 with anti-rotational points
ENVIRONMENTAL
Ambient operating temperature	Up to 40 degrees Celsius
CONSTRUCTION & CONTROL
Body	ABS polycarbonate
Cooling	Passive heat sink
Multi-function button	Power / lock screen
POWER
Input voltage	6.2V to 16.8V
OPERATING POWER
Compatible batteries	NPF L series
Built in battery	No
Continuous power	Via NPF battery and USB-C PD Power
DC in connector	Via Battery Eliminator (optional)
DTAP	Via Battery Eliminator and optional D-Tap to DC barrel cable
USB PD IN
USB PD OUT	> 13W
WHAT’S IN THE BOX
Accessories included	Shinobi II, USB-C 2.0 cable, HDMI and USB-C locking cable adapter, Quick Start Guide
Optional extras	Quick Release Monitor mount, NP-F Battery Eliminator, DC to Dtap Cable, Power Kit, HDMI cables, USB-C to serial cable
WARRANTY
Standard	1 year. Extended to 2 years on product registration.
