USED Sony PVM-A170 17-inch Trimaster OLED HD Monitor

We currently have in Excellent condition a Sony PVM-A170 Monitor complete with a V-Mount Battery Plate, Marshall C-Mount Stand Bracket, Hoodman and Peli Case available for immediate delivery

Slim, lightweight and robust OLED monitor ideal for 4K production, shopping channels, field and graphics applications, as well as OB vans

The PVM-A170 17-inch, Full HD monitor achieves the industry-leading lightweight and shallow body*, with an approximately 40 per cent reduction compared to the previous PVM-1741A model. It is easy to carry, even by one person. The PVM-A170 incorporates the TRIMASTER EL™ OLED panel and offers the industry’s widest viewing angles of any professional flat-panel monitor on the market, making group monitoring easy. The stylish new design also includes a robust, optional protection panel and corner bumpers**. The latest camera-linkage functions, such as camera and lens metadata display and a Picture and Picture function, provide the convenience of working efficiency both in the field and in the post process. Version 2.0 of the PVM-A170 expands and enhances the monitor’s ability to support 4K production, shopping channels, field and graphics applications.

* Comparing professional broadcast monitors incorporating SDI interface(s) and built-in AC power.

** Requires optional BKM-PP17 protection kit.

Stylish lightweight and slim body with the industry’s widest viewing angle

Robust and stylish sharp edges chassis. Perfect for group monitoring. The PVM-A170 weighs 4.2 kg and is approx. 40% thinner than the previous PVM-1741A model. It provides cost savings for transportation and power consumption. It also saves space and weight in digital galleries.

4K production features

The PVM-A170 V2.0 fulfils the demand for an affordable HD monitor in a 4K system. The unit supports the ITU-R BT.2020 colour space and accepts one of the Quad-link 2SI 3G-SDI signals. To fully utilise its wide colour gamut, the monitor offers DCI-P3 and S-GAMUT/S-GAMUT3/S-GAMUT3.cine settings, with proper EOTFs such as 2.6 gamma, S-Log3(SDR) and S-Log2(SDR).

Shopping channels feature

Shopping channels require a unique screen layout to instantly differentiate between a product and its commercial data. The monitor allows you to set two flexible area markers anywhere on the screen

Enhanced field application features

The monitor is ideal for field applications, with sync-free side-by-side, false colour and audio muting functions. You can monitor two pictures without synchronisation. False colour allows you to check the exposure level of a camera at a glance from a distance. Audio muting helps you start shooting quickly.

Graphics applications features

The monitor accepts a computer signal through HDMI. To fully utilise its wide colour gamut, the monitor also offers Adobe RGB and sRGB settings in colour space, and D50 preset in colour temperature.

Latest camera-linkage functions

Includes camera and lens metadata display* and a Picture and Picture function with side-by-side, wipe, blending, difference and auto input switching. Ideal for OnSet and live production monitoring.

*Lens metadata is supported by F65, PMW-F55, PMW-F5, PXW-FS7M2 and PXW-FS7 as well as equipment capable of SMPTE RDD18.

User presets and password protection

Secure your monitor settings for greater peace of mind. Five user presets are available. One colour temperature memory USER1 can also be password protected.

2K format display and Dual-Link HD-SDI mode

This feature offers a cost-effective 2K monitoring solution, ideal for OnSet digital cinematography. In addition, a Dual-link HD-SDI input is available.

Multiple monitors firmware upgrade utility

Save you time to upgrade simultaneously your monitors through your network.

SPECIFICATIONS

Picture Performance
Panel
OLED panel

Picture Size (Diagonal)
419.7 mm (16 1/2 inches)

Effective Picture Size (H x V)
365.8 x 205.7 mm (14 1/2 x 8 1/8 inches)

Resolution (H x V)
1920 x 1080 pixels (Full HD)

Aspect
16:9

Panel Drive
RGB 10-bit

Viewing Angle (Panel Specification)
89°/89°/89°/89° (typical) (up/down/left/right contrast > 10:1)

Input
Composite Input
BNC (x1), 1.0 Vp-p ±3dB sync negative

SDI
Input BNC (x2)

HDMI Input
HDMI (x1) (HDCP correspondence)

Audio Input
Stereo mini jack (x1), -5 dBu 47 kΩ or higher

Parallel Remote
RJ-45 modular connector 8-pin (x1) (Pin-assignable)

Serial Remote (LAN)
RJ-45 modular connector (x1) (Ethernet, 10BASE-T/100BASE-TX)

DC Input
XLR-type 4-pin (male) (x1) DC 12 V to 16 V (output impedance 0.05 Ω or less)

Output
Composite Output
BNC (x1), Loop-through, with 75 Ω automatic termination

SDI Output
BNC (x2)
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 Ω unbalanced

Audio Monitor Output
Stereo mini jack (x1)

Speaker (Built-in) Output
1.0 W (mono)

Headphone Output
Stereo mini jack (x1)

General
Power Requirements
AC 100 V to 240 V, 0.9 A to 0.5 A, 50/60 Hz DC 12 V to 16 V, 6.4 A to 4.8 A

Power Consumption
Approx. 75 W (AC power supply) (max.)
Approx. 60 W (AC power supply) (average power consumption in the default status)

Operating Temperature
0°C to 35°C (32°F to 95°F)
Recommended: 20°C to 30°C (68°F to 86°F)

Operating Humidity
30% to 85% (no condensation)

Storage / Transport Temperature
-20°C to +60°C (-4°F to +140°F)

Storage / Transport Humidity
0% to 90%

Operating / Storage / Transport Pressure
700 hPa to 1060 hPa

Dimensions (W x H x D)
435.0 x 274.0 x 65.5 mm* (17 1/4 x 10 7/8 x 2 5/8 inches) (without monitor feet)
435.0 x 296.5 x 165.0 mm (17 1/4 x 11 3/4 x 6 1/2 inches) (with monitor feet)

Mass
Approx. 4.2 kg (9 lb 4.2 oz)
