YoloLiv YoloBox Extreme 8 Input Encoder / Switcher / Recorder / Monitor All in One - YOLOBOXEXTREME

**DUE TO SHIP ON 27th MARCH 25**

FEATURES

8 Input Encoder, switcher, recorder, monitor, in One
ISO Recording - Up to 4*4K30 or 6*1080P60
Real 4K Streaming
8 HDMI Inputs - Up to 4*4K60 with Built-in Scaler
2 HDMI Outputs - Assignable Program/Multiview Out in 4K
Up to 8 NDI Inputs - Connect Wirelessly or via Ethernet
OLED - 11.2 Inch,2.5K Resolution, 120hz Fresh Rate
Qualcomm 8Gen2 - Outsized Performance
MultiCam Instant Replay - 6 Cam at 1080P60 or 4 Cam at 4K30
External Antenna - Up to 90m Wireless Range & Connectivity
Up to 10-Hour Battery Life
Next-Level I/O Versatility
Next Level Production Flexibility

Perfect for On-Location & One-Man Crew

No Computer Required. Set up in Minutes.

All-In-One
Encoder, switcher, recorder, monitor, in One
Android System
Users can benefit from regular updates while enjoying an intuitive and familiar interface that enhances usability.
Minimum Setup
No computer/desk workstation/professional crew required
Portability & Mobility
It is compact, fits into your backpack, and lives On the Go.
Battery-Powered
10 Hour Battery Life + Built-In 4G LTE, WiFi, Ethernet
Touchscreen Control
Production at your fingertip, great ease to operate

8 HDMI Input - More is Better

Seamlessly Connect Cameras, Laptops, Media Players, and More, Offering Unmatched Flexibility for Any Scenario.
Future-Proof Your Setup Without Worrying About Running Out of Ports.

HDMI Inputs (1-8): Up to 4*4K60 with Built-in Scaler
HDMI Outputs (1-2): Assignable Program/Multiview Out in 4K
Ethernet Connection: Wired Stable internet connection
USB Type-A 3.0 (1-2): For Webcams; Hard drives; USB dongles.
Mic In (3.5mm): Mono, connect to the wired microphone
Line In (3.5mm): Stereo, connect to an external audio mixer
USB Type-C: A fully functional interface supports input
USB Type-C: Only for Charging
Audio Out (3.5mm): Connect to headphones for monitoring
SD Card Holder: Save files; Load videos & graphics.
Nano-SIM Card Holder: Insert SIM card for 4G network
Standard ¼‘’mounting hole: Mount with other cameras & tripods
Power Button: Turn on & off, Sleep Mode

Dual Assignable HDMI Outputs

Allowing You to Output Different Video Feeds( Preview, Multiview or Program) Simultaneously.

Bigger than ever | Brighter than ever | Smoother than ever

More Space to Explore
The all-new 11.2-inch OLED screen brings a larger, more immersive display, redefining how you see and interact with content.
Shine in Any Light
With a peak brightness of up to 800-1,000 nits, every detail remains vivid and clear, even under direct sunlight.
Effortlessly Responsive
Enjoy ultra-fast touch feedback for a silky-smooth experience, making every interaction seamless and intuitive.

Configure directly & Intuitively from YoloBox

The benchmark for performance is ease of use.

Live Switch
Easily switch between multiple video sources or fully customized scenes with a touch.
Audio Mixing
Built-in audio mixer with easy setup. Individual level control of multiple audio sources.
ISO Recording
Capture all the video inputs as well as the program video and save them separately.
Graphic Overlays
Add logos, lower thirds, titles, countdown timer and more to look professional.
MultiViews
Customize live stream layout with built-in multiviews and level up production with ease.
Scoreboard
YoloBox’s built-in scoreboards allow you to keep the score in real time, display game progress, add game/team logos, and more.
MultiCam Replay
Create highlight clips with preset video duration, intros, outro and more with a few clicks.
Inviting Guests
Create a real-time conversation with remote guests from a web browser on mobile devices.
PTZ Control
With PTZ control, you can preset up to 5 camera positions. This allows you to quickly switch between different angles and views.
Crop Video
Video cropping serves various needs such as margin removal, game capture resizing, conferencing zooming, and close-up view creation.
Chroma Key
Seamlessly add a different background of a design or a different location for your live productions with the magic of a chroma key in a few taps.
AutoSwitch
Seamless Transition between pre-set camera angles with defined order and duration. Frees you from manual camera control to focus on the video.

Advanced Features as Standard

Free MultiStreaming
Customized MultiView Out
4K Streaming
App/Web Control Control
Inviting Guests
Web URL Overlay
Video Follow Audio
Custom Layouts(Scene Building)

Audio Investment Evolved

Assignable AFV
Each audio channel automatically switches as the video changes, ensuring perfect synchronization.
Mix-Minus
Easily solo monitor a specific audio channel or mute it entirely, giving you full control.
Audio Delay
For any sync issues between audio and video, simply adjust the timing to ensure synchronization.

SPECIFICATIONS

Input Power

9V / 12V / 15V⎓3A

Power Consumption

45W

Power Supply

USB Type-C

USB Rated Output

USB-A:5V/1A

Battery Capacity

10000mAh

Dimensions

264*167*29mm

Power Consumption

＜45W

Monitor Screen Size

11.2inch 2K OLED; Resolution: 2560x153;
Brightness: 450nits ( ≈ LCD 800-1000nits);
Frequency: Fre =120Hz; Contrast ratio (1500:1);
Viewing Angle (full viewing Angle); NTSC 108%

Local Video Inputs

HDMI USB-A

Video Over Ethernet

RTMP/RTMPS/SRT/NDI/RTSP

Video Input Connectors

HDMI, USB-A, RJ-45, USB Type-C

Video Input Aspect Ratios

16:9, 4:3, 1:1

Video Input Deinterlacing

Live Broadcast Video Input Resolution

480p/720p/1080p(up to 60fps)/4Kp60

Video Encoded Format

H.264 H.265

Video Processing Bitrate Control

CQ, VBR, CBR

Hardware-accelerated Video Encoding

Optional

Video Output Signal Types

FLV-RTMP, HDMI, UVC

Video Output Connectors

HDMI OUT, USB-C

Video Output Streaming Protocols

RTMP, RTMPS, MJPEG, SRT

Live Broadcast Video Output Resolution

480p/720p/1080p(Up to 60fps)/4Kp60

Analog Audio Input Connectors

Line In; Mic In; 3.5mm

Digital Audio Outputs

USB; HDMI; RTMP (From internet);
Local video (From SD card)

Digital Audio Input Connectors

USB-A, HDMI, USB-C

Audio Input Mute

Yes

Audio Input Format

32KHZ/44.1KHZ/48KHZ :16bit

Audio Encoded Format

(AAC)44.1K/48KHZ 2Ch 16bit

Analog Audio Output

3.5mm Headphone Jack

Digital Audio Outputs

HDMI Audio (Embedded); USB Audio (Embedded)

Record Formats

MP4

Wi-Fi

2.4G/ 5G (Support WiFi6/WiFi7)

USB Communication Standard

USB 2.0 and USB 3.0

Ethernet Data Rate

10/100/1000m, Half/full Duplex With Autodetect

SIM Card Size

Nano-SIM Card

4G Network

4G Network Countries & Frequency Band For
Users: [Variant for North Americao (US/Canada/Mexico)]
B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B66/B71
Notes: Mexico B4 For Non-US/Canada/Mexico
Users: (EU：Variant for EMEA/India/Korea/Taiwan/South
Asia/Latin/America/Australia/New Zealand)
Users:B1//B3/B7/(B8) Notes：Thailand B1/B3

Please note that the certification of Yolobox Extreme is in line with the mainstream open 4G band requirements of operators in this country or region. For details, please refer to the approval report of this country or region.

SD Card Format

FAT32(Under 128G); NTFS; EX-FAT

Operating Temperature

0℃-40℃

Operating Humidity

15%-85%; No Condensation

Country of Origin

Made in China
