Description
AJA Io X3 Multi-Channel 2K/HD/SD Video I/O over Thunderbolt 3 - IoX3-R0
FEATURES
2K/HD/SD I/O up to 50/60p
4x bidirectional 3G-SDI BNC with 16-channel embedded audio
HDMI I/O with 8-channel embedded audio
Two Thunderbolt 3 ports with loop-through
Multi-channel workflow support for OBS/Wirecast/vMix and other applications
YCbCr 4:2:2 10-bit up to 60p
RGB 4:4:4 12-bit up to 30p
VPID signalling for SDR/HDR Transfer Characteristics, Colorimetry and Luminance via SDI
PQ, HLG, HDR10, HDR10+ and Dolby Vision Support
HDR Metadata Capture and Auto Playback Detection
Multiview output over HDMI, to view up to 4-channels on one screen
Analog audio flexibility with a choice of 8-channel In or 8-channel Out or 4-channel In and 4-channel out via a standard Tascam connection
Front panel audio display
Includes support for the Apple M1 chip and the latest OS versions
XLR 12V power for battery or AC use (AC adapter included)
Headphone jack and level control for mobile and live environments
RS-422 VTR control, Reference, LTC Input and LTC Output
Versatile and Practical Connectivity
The Io X3 rear panel offers a wealth of easy to access connectivity for almost any need in SD/HD/2K video pipelines. Power is supplied via industry-standard 4-pin XLR with either the included AC adapter or battery power. Dual Thunderbolt 3 ports provide host connectivity to a laptop or desktop PC or Mac, with the second port for looping through to other Thunderbolt devices. RS-422 is included for machine control of external devices so they can be synchronized for editing. Analog audio is offered via a DB-25 port, with all 8-channels configurable to be in or out. HDMI in and out ports allow for easy monitoring or video input sources to be accessed, including HDR and SDR video. Reference input connects the Io X3 to any master clock source alongside LTC input and output for timecode. Finally, 4 bidirectional 3G-SDI ports can be configured as multi-channel inputs or outputs to suit the video application of choice, offering immense flexibility in the field, editing suite or on-set.
SPECIFICATIONS
Video Formats
- (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
- (2K) 2048 x 1080PsF 23.98, 24, 25
- (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
- (HD) 1080PsF 23.98, 24, 25, 29.97, 30
- (HD) 1080i 50, 59.94, 60
- (HD) 720p 50, 59.94, 60
- (SD) 625i 50
- (SD) 525i 59.94
Note: High Frame Rate support is dependent on Thunderbolt speed and system performance. Not all host systems will support all frame rates.
Video Input Digital
- 3G-SDI, SMPTE 425
- RGB 4:4:4 12-bit*, YCbCr 4:2:2 10-bit
- 1.5G-SDI, SMPTE 292M
- Single Link HD-SDI YCbCr 4:2:2 10-bit
- 270 Mbps SDI, SMPTE 259M-C
- YCbCr 4:2:2 10-bit, 8-bit
- HDMI v1.4b
- 30/36-bits/pixel, RGB or YUV, 2.25 Gbps
- 2K, HD, and SD
*Bit depth support is application dependent. Check with your software manufacturer for compatibility.
Video Output Digital
- 3G-SDI, SMPTE 425
- RGB 4:4:4 12-bit*, YCbCr 4:2:2 10-bit
- 1.5G-SDI, SMPTE 292M
- Single Link HD-SDI YCbCr 4:2:2 10-bit
- 270 Mbps SDI, SMPTE 259M-C
- YCbCr 4:2:2 10-bit, 8-bit
- HDMI v1.4b
- 30/36-bits/pixel, RGB or YUV, 2.25 Gbps
- 2K, HD, and SD with HFR support up to 60p (4:2:2), 10-bit
*Bit depth support is application dependent. Check with your software manufacturer for compatibility.
HDR
- SDI: VPID signaling for SDR/HDR Transfer Characteristics
- HDMI: HDR10 Support - HDR Infoframe metadata, compatible with HDMI 2.0a/CTA-861.3
- HDMI: HLG Support - compatible with HDMI 2.0b/CTA-861-G
Note: HDR support is application dependent. Check with your software manufacturer for compatibility.
Audio Input Digital
- 16-channel, 16 and 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous
- 8-channel, 16 and 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Digital
- 16-channel, 16 and 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous
- 8-channel, 16 and 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Input Analog
- 8-channel, 24 and 16-bit D/A analog audio, 48 kHz sample rate, balanced, using industry standard 8x XLR on DB-25 breakout cable (cable not included)
- +24 dBu full scale digital (0 dBFS)
- +/- 0.2 dB 20 to 20 kHz frequency response
- Input supported across Ch 1-8, Ch 1-4, or Ch 5-8 depending on configuration chosen
Audio Output Analog
- 8-channel, 24-bit D/A analog audio, 48 kHz sample rate, balanced, using industry standard 8x XLR on DB-25 breakout cable (cable not included)
- +24 dBu full scale digital (0 dBFS)
- +/- 0.2 dB 20 to 20 kHz frequency response
- Output supported across Ch 1-8, Ch 1-4, or Ch 5-8 depending on configuration chosen
- 2-channel, 18-bit D/A analog audio, 48 kHz sample rate, unbalanced, using standard 3.5mm jack
- 1.2V RMS full scale digital output level (0 dBFS)
Downstream Keyer
- Supports graphics up to 2K/HD with alpha channel over video, matte or framebuffer, or framebuffer content over incoming video or matte
LTC
- 1x BNC LTC input (dedicated)
- 1x BNC LTC output (dedicated)
Reference
- 1x BNC (dedicated)
- Analog Color Black (1V) or Composite Sync (2 or 4V)
- Nonterminating
Electrical Interface
- Thunderbolt 3 (2x)
Machine Control
- RS-422, Sony 9-pin protocol
- 9-pin D-connector pinout is as follows:
|
1 |
GND |
| 2 | RX- |
| 3 | TX+ |
| 4 | GND |
| 5 | No Connection |
| 6 | GND |
| 7 | RX+ |
| 8 | TX- |
| 9 | GND |
| Shell | GND |
Size (w x d x h)
- 8.74" x 7.09" x 1.65" (222.0 x 180.09 x 41.91 mm)
Weight
- 3.1 lbs. (1.5 kg)
Power
- 10-20V, 23W typical, 28W max
Environment
- Safe Operating Temperature Range: 0 to 35 C (32 to 95 F)
- Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
- Operating Relative Humidity: 10-90% noncondensing
- Operating Altitude: <3,000 meters (<10,000 feet)
