Description

AVMatrix SHARK S6 PLUS 6-Channel SDI/HDMI Portable Video Switcher with 17.3-inch Screen

FEATURES

  • Video Switcher for Streaming & Recording
  • 17.3" FHD IPS Multiview Display
  • Four SDI & Two 4K HDMI Inputs
  • Four SDI, Two 4K HDMI, USB-C Outputs
  • USB, SD & SATA Recording Support
  • RTMP, SRT & RTSP Streaming Compatibility
  • Control up to 6 PTZ Cameras via IP
  • Chroma-Key, Luma Key, PiP & Logo Overlay
  • XLR Mic Audio I/O with 48V Phantom Power
  • VISCA, ONVIF& Pelco P/D PTZ Control

S6 Plus, view 2S6 Plus, view 3S6 Plus, view 4S6 Plus, view 5S6 Plus, view 6S6 Plus, view 7S6 Plus, view 8S6 Plus, view 9S6 Plus, view 10S6 Plus, view 11S6 Plus, view 12S6 Plus, view 13S6 Plus, view 14S6 Plus, view 15

SPECIFICATIONS

Mix Effects
Available M/E Layers
6 M/E
Effect Types
1x Graphic
1x Chroma Key, Luma Key
Downstream Keys
1x Chroma, Luma
Processing
Switching Type
Pushbutton
Processing Resolution
UHD 4K
Color Processing
10-Bit 4:2:2 YUV
10-Bit RGB
Input
Number of Video Input Sources
6
Video Inputs
4x BNC (3G-SDI) Female
2x HDMI
Input Video Format
SDI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
HDMI
UHD 4K at 30/50/60 fps
DCI 2K at 30/50/60 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
Audio Inputs
2x Combo XLR-1/4" TRS Mic/Line Female
1x 1/8" / 3.5 mm TRS Line Female
Embedded Audio Input
HDMI
SDI
Output
Video Output Channels
3
Video Outputs
2x HDMI (Program)
4x BNC (3G-SDI) (Program)
1x USB-C (Program)
Output Video Format
HDMI / SDI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
Audio Outputs
2x XLR 3-Pin Line Female
1x 1/8" / 3.5 mm TRS Line Female
Embedded Audio Output
HDMI
SDI
Multiview Output
4-Way Multiview via HDMI
Monitor Output
1x HDMI
Connectivity
Other I/O
1x BNC Reference Input
1x BNC GPI Input
1x DE-15/DB-15 Tally Input/Output
1x DE-9/DB-9 Control, RS-232, RS-422 Input/Output
IP Encoding/Decoding
IP Video
1920 x 1080 at 60p (32 Mb/s) Encoding
Transport Protocols
HTTP, RTMP, RTMPS, RTSP, SRT
Simultaneous Streams
2 Streams
Internal Recording
Recording Media
1x SD (Unspecified Type), USB-A 2.0
Recording Modes
1920 x 1080p up to 60 fps (200 Mb/s MP4 via H.264/AVC)
Display
Display Size
17.3"
Screen Resolution
1920 x 1080
Hardware
Processor
Not Specified by Manufacturer
Wireless
No
Power
Power I/O
1x Barrel (9 to 24 VDC ) Input
Power Consumption
Device: 50 W
General
Operating Conditions
-4 to 122°F / -20 to 50°C
Storage Conditions
-22 to 158°F / -30 to 70°C
Dimensions
17.3 x 11.1 x 2.6" / 440 x 281.5 x 65.1 mm
Weight
8.11 lb / 3.68 kg
