AVMatrix UC1118 3G-SDI to USB Video Capture Box
AVMatrix UC1118 3G-SDI to USB Video Capture Box
AVMatrix UC1118 3G-SDI to USB Video Capture Box
Roll over image to zoom in Click on image to zoom
AVMatrix UC1118 3G-SDI to USB Video Capture Box
AVMatrix UC1118 3G-SDI to USB Video Capture Box
AVMatrix UC1118 3G-SDI to USB Video Capture Box

AVMatrix UC1118 3G-SDI to USB Video Capture Box

AVMatrixSKU: UC1118

Need this in a hurry? Check current lead times for AVMatrix

Price:
£150.00(incl. VAT)
£125.00

(ex VAT)

Tax included

Stock:
Available to backorder
Shipping: Calculated at checkout

Payment & Security

Apple Pay Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

AVMatrix UC1118 3G-SDI to USB Video Capture Box

FEATURES

  • 3G/HD/SD-SDI In / USB 3.1 Type-C Out
  • Up to 1920 x 1080p60 / Auto-Detection
  • Uncompressed Video & Audio Capture
  • UVC & UAC Compatible
  • Plug-and-Play, Driver- & Power-Free
  • Supports YUV Video Output
  • For Windows, Linux & macOS
  • For OBS, Zoom, Teams, Twitch & More

The AVMatrix UC1118 is a video capture and conversion system which allows for the transformation of a 3G-SDI video input across to a USB 3.1 compatible video signal. It's useful if you are using an SDI camera to capture video streams and need to have them available for USB transport into a piece of software - such as a capture program, or a live stream.

SPECIFICATIONS

Inputs/Outputs
Video Inputs
1x BNC (3G-SDI)
Audio Inputs
1x 1/8" / 3.5 mm TRS Stereo
Format Support
Input Video Format
SDI
1080p at 24/25/29.97/30/50/59.94/60 fps
1080PsF 23.98/24/25/29.97/30 fps
1080i 50/59.94/60 fps
720p 23.98/24/25/29.97/30/50/59.94/60 fps
576i / 625 lines 50 fps
480i / 525 lines 59.94 fps
Input Audio Format
Analog: 48 kHz / 16-Bit
Output Video Format
USB-C
1080p
WUXGA (1920 x 1200)
WUXGA+ (1680 x 1050)
UXGA (1600 x 1200)
WXGA+ (1440 x 900)
FWXGA (1366 x 768)
1280 x 960
SXGA (1280 x 1024)
WXGA (1280 x 800)
720p
XGA (1024 x 768)
1024 x 576
960 x 540
856 x 480
SVGA (800 x 600)
576i / 625 lines
480p
VGA (640 x 480)
640 x 360
Output Audio Format
USB Audio
Embedded Audio
SDI/USB: 2-Channel
Hardware
OS Compatibility
Windows
Linux
macOS
Power
Power Consumption
Device: 3.5 W
Environmental
Operating Temperature
12 to 92°F / -20 to 60°C
Storage Temperature
-22 to 158°F / -30 to 70°C
Operating Humidity
20 to 90%
General
Dimensions
36.2 x 22.8 x 7.5" / 92 x 58 x 19 cm
Weight
7.2 oz / 205 g
