AVMatrixSKU: UC2018

Need this in a hurry? Check current lead times for AVMatrix

Price:
£165.00(incl. VAT)
£137.50

(ex VAT)

Tax included

Stock:
Available to backorder
Shipping: Calculated at checkout

Payment & Security

Apple Pay Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

AVMatrix UC2018 Bi-directional 4K60 HDMI to NDI Video Encoder

FEATURES

  • Supports up to 1920 x 1080p60 Resolution
  • Hardware Scaling and Deinterlacing
  • Performs Frame Rate Conversion
  • UVC Compatible
  • Supports YUV 4:2:2 Video Output
  • For Windows, Linus, and macOS
  • Works with Third-Party Capture Software
  • USB Powered

The AVMatrix UC2018 is a video capture and conversion system which allows for the transformation of an HDMI or  3G-SDI video input across to a USB 3.1 compatible video signal. It's useful if you are using an HDMI or SDI camera to capture video streams and need to have them available for USB transport into a piece of software - such as a capture program, or a live stream.

FEATURES

Inputs/Outputs
System Connection
USB-C 3.0 / 3.1/3.2 Gen 1
Video Inputs
1x BNC (3G-SDI)
1x HDMI (1.4a)
Audio Inputs
1x 1/8" / 3.5 mm TRS Stereo Line
Format Support
Input Video Format
SDI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
HDMI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
576p at 50 fps
576i / 625 lines at 50 fps
480p at 59.94/60 fps
480i / 525 lines at 59.94/60 fps
Input Audio Format
LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit
Output Video Format
USB-C
WUXGA (1920 x 1200)
1080p
1650 x 1050
UXGA (1600 x 1200)
WXGA+ (1440 x 900)
1360 x 768
SXGA (1280 x 1024)
1280 x 960
WXGA (1280 x 800)
1280 x 720 (Non-Standard WXGA)
XGA (1024 x 768)
1024 x 576
960 x 540
856 x 480
SVGA (800 x 600)
768 x 576
720 x 576
720 x 480
VGA (640 x 480)
640 x 360
Output Audio Format
LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit
Embedded Audio
HDMI/SDI/USB
Hardware
Tally Light
Yes
OS Compatibility
Windows 7 to 10
Linux 2.6.38 or Later
macOS 10.8 or Later
Power
Power I/O
1x USB-C Input
Power Consumption
3.5 W
Environmental
Operating Temperature
32 to 122°F / 0 to 50°C
Storage Temperature
32 to 140°F / 0 to 60°C
Operating Humidity
20 to 90%
General
Dimensions
3.6 x 2.3 x 0.7" / 92 x 58 x 19 mm
Weight
7.2 oz / 205 g
