AVMatrix VC41 4 channel 3G-SDI PCI Express Capture Card

AVMatrixSKU: VC41

Need this in a hurry? Check current lead times for AVMatrix

Price:
Sale price£0.00(incl. VAT)
£0.00

(ex VAT)

Tax included

Stock:
Available to backorder
Shipping: Calculated at checkout

Payment & Security

Apple Pay Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

AVMatrix VC41 4 channel 3G-SDI PCI Express Capture Card

FEATURES

  • PCIe 2.0x4 Interface
  • 4 x 3G-SDI Input
  • Supports up to 1080p60 Video
  • Simultaneously Stream and Capture
  • YUY2 Uncompressed Video
  • For Windows and Linux OS

SPECIFICATIONS

Inputs/Outputs
System Connection
PCIe 2.0 x4
Video Inputs
4x BNC (3G-SDI) Female
Audio Inputs
No
Simultaneous Multi-Input Support
Yes: 4 Simultaneous Inputs
Format Support
Input Video Format
SDI
1080p 60 fps
Input Audio Format
LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit
Output Video Format
SDI
1080p 25/30/50/59.94/60 fps
UXGA (1600 x 1200) 60 fps
HD+ (1600 x 900) 60 fps
WXGA+ (1440 x 900) 60 fps
SXGA (1280 x 1024) 60 fps
WXGA (1280 x 800) 60 fps
1280 x 720 (Non-Standard WXGA) 25/30/50/59.94/60 fps
XGA (1024 x 768) 60 fps
SVGA (800 x 600) 30/60 fps
576p 30/60 fps
480p 30/60 fps
Output Audio Format
LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit
Embedded Audio
SDI
Standards
HDR Support
Not Specified by Manufacturer
Hardware
OS Compatibility
Windows 7 or Later
Linux 18.4 or Later
Power
Power Consumption
Device: 2 W
Environmental
Operating Temperature
32 to 140°F / 0 to 60°C
Storage Temperature
-4 to 158°F / -20 to 70°C
Operating Humidity
5 to 90% ()
General
Dimensions
4.7 x 3.5 x 0.9" / 120.1 x 88.4 x 21.6 mm
Weight
5.3 oz / 150 g
