Fairlight Audio Interface - DV/RFL/AUDIF
Fairlight Audio Interface - DV/RFL/AUDIF
Roll over image to zoom in Click on image to zoom
Fairlight Audio Interface - DV/RFL/AUDIF
Fairlight Audio Interface - DV/RFL/AUDIF

Fairlight Audio Interface - DV/RFL/AUDIF

FairlightSKU: DV/RFL/AUDIF
Price:
£2,070.00(incl. VAT)
£1,725.00

(ex VAT)

Tax included

Stock:
In stock
Shipping: Calculated at checkout

Payment & Security

Apple Pay Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

Fairlight Audio Interface - DV/RFL/AUDIF

Professional audio post production I/O interface

FEATURES

  • For Postproduction Engineers
  • Proprietary Fairlight Host Connectivity
  • Inputs: 2 Mic/Hi-Z Pres, 8 Line, 20 AES
  • Outputs: 12 Line, 24 AES
  • 24-Bit / 192 kHz AD/DA Converters
  • Internal Power Supply / Mac and Windows
  • Phantom Power, Timecode and GPIO In/Out
  • BNC Wordclock and Video Sync I/O
  • RS-422 Machine Control I/O
  • Multi-Segment Level Indicators

Fairlight Audio Interface is a professional audio post production I/O interface with an extensive variety of analog and digital inputs and outputs, preamps for microphones and instruments, built in sample rate conversion, sync at any standard frame rate and dual 9?pin control ports. Fairlight Audio Interface requires Fairlight Audio Accelerator and connects to the Fairlight Audio Interface with a supplied proprietary interface cable.

SPECIFICATIONS

General
Display
12x Multi-Segment LED Meter
Channels of I/O
Analog:
10 Inputs / 12 Outputs
Digital:
20 Inputs / 24 Outputs
Maximum Sampling Rate
192 kHz / 24-Bit
Number of Microphone Inputs
2
Input Level Adjustment
2x via Software
Signal Processing
Pad
No
Gain/Trim Range
Mic Inputs:
+21.5 to +71.5 dB
Hi-Z Inputs:
+0 to +50 dB
High-Pass Filter
No
Solo/Mute
No
Connectivity
Analog Audio I/O
2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Hi-Z Input (Front Panel)
1x DB-25 25-Pin Balanced Line/8-Channel Input (AES 59/Tascam Pinout)
1x DB-25 25-Pin Balanced Line/8-Channel Output (AES 59/Tascam Pinout)
4x 1/4" TRS Balanced Line Output
Phantom Power
48 V, Selectable On/Off
Digital Audio I/O
1x RCA Coaxial AES3 / S/PDIF Input
1x RCA Coaxial AES3 / S/PDIF Output
2x DB-25 AES3 In & Out (AES 59/Tascam Pinout)
Host Connection
1x DVI-D (DL)
Host Connection Protocol
Blackmagic Design Fairlight Proprietary
USB (Non-Host)
No
Sync I/O
1x BNC Word Clock Input
1x BNC Word Clock Output
1x BNC Video Sync Input
1x BNC Video Sync Output/Thru
Network I/O
No
MIDI I/O
1x DIN 5-Pin Input
1x DIN 5-Pin Output
Expansion Slots
No
Other I/O
1x DB-25 25-Pin GPIO In/Out
1x DE-9/DB-9 9-Pin Control Input
1x DE-9/DB-9 9-Pin Control Output
Performance
Frequency Response
Inputs:
20 Hz to 20 kHz ±0.05 dB
Outputs:
20 Hz to 20 kHz +0.05/-0.5 dB
Maximum Input Level
Mic Inputs:
+2.5 dBu
Line/Hi-Z Inputs:
+24 dBu
Maximum Output Level
Analog Outputs:
+24 dBu
Impedance
Mic Inputs:
2 Kilohms
Hi-Z Inputs:
> 1 Megohm
Line Inputs:
15 Kilohms
Analog Outputs:
50 Ohms
BNC Inputs:
75 Ohms
BNC Inputs:
75 Ohms
Dynamic Range
Combo XLR-1/4" Inputs:
108 dB (Unweighted, Min Gain)
DB-25 Inputs:
110 dB (Unweighted)
Outputs:
109 dB (Unweighted)
THD+N
Combo XLR-1/4" Inputs:
0.001% (Unweighted, 1 kHz, Min Gain, at -1 dBFS)
DB-25 Inputs:
0.001% (Unweighted, 1 kHz)
Outputs:
0.002%
EIN
Mic Inputs:
-127 dBu (150-Ohm Source, +40 dB Gain)
Digital Audio
Sample Rates
44.1 / 48 / 96 / 192 kHz
Sample Rate Conversion
On S/PDIF Inputs
Bit Depths
24-Bit
Sync Sources
AES3, Internal, S/PDIF, Word Clock
Compatibility
OS Compatibility
macOS 10.15 or Later
Windows 10 (64-Bit Only)
Mobile Device Compatibility
No
Power
Power Requirements
AC Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
40 W
Physical
Rackmount Size
1 RU
Operating Humidity
0 to 90%
Operating Temperature
32 to 104°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Dimensions
18.97 x 11 x 1.74" / 48.18 x 27.9 x 4.42 cm
Weight
9.0 lb / 4.1 kg
