Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker WM-8P-(B)-(SINGLE) - 8" 2-way passive wall mounted speakers black (single)
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker WM-8P-(W)-(SINGLE) - 8" 2-way passive wall mounted speakers white (single)
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker
Roll over image to zoom in Click on image to zoom
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker WM-8P-(B)-(SINGLE) - 8" 2-way passive wall mounted speakers black (single)
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker WM-8P-(W)-(SINGLE) - 8" 2-way passive wall mounted speakers white (single)
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker
Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker

Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker

Kramer ElectronicsSKU: WM-8P-1

Need this in a hurry? Check current lead times for Kramer Electronics

OPTIONS: WM-8P-(B)-(SINGLE) - 8" 2-way passive wall mounted speakers black (single)
Price:
£210.00(incl. VAT)
£175.00

(ex VAT)

Tax included

Stock:
In stock
Shipping: Calculated at checkout

Payment & Security

Apple Pay Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

Kramer WM-8P 8-inch Two-Way Wall Mounted Passive Speaker

FEATURES

  • Superb sound with stylish design
  • Low–impedance (8Ω) / high–impedance (70V/100V)
  • Power handling: 60W continuous / 80W peak
  • Nominal sensitivity: 90dB SPL
  • Maximum SPL: Continuous 108dB SPL / Peak 109dB SPL
  • UL1480A certified
  • Available in black & white colors
  • Eco–friendly packaging

The WM−8P wall mounted passive speaker deliver exceptional sound performance for commercial indoor applications. The WM−8P is a high−end 8” wall mounted passive speaker featuring exceptional sound, optimized for conferencing and background music. The speaker supports both 8Ω low impedance as well as several 70V/100V high impedance modes. The speaker is supplied with Kramer’s EasyMount mounting bracket for horizontal and vertical installations as well as for installation in corners, in addition the speaker has standard 75mm VESA mount threads for additional installation options. The speaker is available in both black & white colors.

Key Features

  • Exceptional sound performance
  • Low–impedance (8Ω) / high–impedance (70V/100V)
  • Power ratings: 60W continuous / 80W peak
  • Sensitivity (1W@1m, free field): 90dB SPL
  • Maximum SPL (@1m): Continuous 108dB SPL / Peak 109dB SPL
  • UL1480A certified
  • Industrial design: hidden wall–mount bracket for horizontal, vertical and cornet installation, standard 75mm VESA mount threads, removable logo, available in black & white colors
  • Eco–friendly mono–material packaging

WHAT'S IN THE BOX

  • Included in the Box — 1 speaker (single unit), 2 speakers are packed in a single master box
    1 EasyMount mounting bracket + 2 bracket screws
    4–pin pluggable Euroblock connector, 28–12AWG
    L–shaped Allen key (M6)
    Quick Start Guide

SPECIFICATIONS

Audio

Driver:
LF Driver:
200 mm (8”) with polypropylene cone and rubber surround
HF Driver:
25 mm (1”) liquid cooled soft–dome tweeter
Frequency characteristics
Frequency Range (-10dB):
60Hz–20kHz
Frequency Response (±3dB)
79Hz–20kHz
Dispersion angle:
124 deg. (1 kHz to 4 kHz)
Power ratings
@ 8Ω Low impedance:
60W continuous / 80W peak
@ 100 V High impedance:
60W/30W/15W
@ 70 V High impedance:
60W/30W/15W/7.5W
Sound Pressure Level (SPL)
Sensitivity (1W@1m, free field)
90dB SPL
Maximum SPL:
Continuous: 108dB SPL / Peak: 109dB SPL

MECHANICAL

Installation
Type:
Surface mounted vertical, horizontal or in corners
Mounting:
EasyMount bracket included, standard 75mm VESA mount threads
Connectors:
4–pin pluggable Euroblock connector, 28–12AWG
Weight per single speaker (including mounting bracket):
5.1kg (11.3lbs)
Dimensions
Dimensions without Bracket:
250mm x 222mm x 390mm / 9.9” x 8.8” / 15.4”
Dimensions with Bracket:
250mm x 306mm x 390mm / 9.9” x 12.1” / 15.4”
Shipping Dimensions (single unit):
422mm x 332mm x 480mm / 16.6" x 13.1" x 18.9"
Shipping dimensions (2 units in a Master box):
670mm x 430mm x 498mm / 26.4" x 17" x 19.6"
Shipping weight (single unit):
7kg / 15.5lbs
Shipping weight (2 units in a Master box):
15Kg / 33lbs
Packaging
Eco–friendly mono–material packaging made entirely from recyclable carton, designed for durability and ease of recycling
Material
Grill:
Powder Coated Steel, removable logo
Baffle:
V–0 Flame Retardant
Bracket:
Aluminium
Environmental
Operating Temperature:
–5° to +50°C (23° to 122°F)
Storage Temperature:
–10° to +55°C (14° to 131°F)
Humidity:
30% to 85%, RHL non–condensing

REGULATORY

UL1480A Certified:
Meets safety standards for fire–protective signaling in commercial spaces.
Environmental
:
RoHS, REACH, WEEE
