Turtle AV Dante Pro Dual Channel USB-C I/O Adapter

FEATURES
  • Converts 2-Channel USB-B Audio to Dante
  • Bidirectional Conversion, Plug and Play
  • Up to 24-Bit / 192 kHz Dante Output
  • Up to 24-Bit / 96 kHz USB Audio Input
  • 1, 2, or 5 ms Dante Audio Delay Options
  • Supports Mic Input and SPK Output
  • PTP for Jitter-Free Audio
  • Rugged All-Metal Chassis
  • Toggle Between AES67 and Dante Output
  • Fully TAA Compliant
High-Performance Audio
This adapter delivers high-quality two-channel USB-B audio and converts it to two-channel Dante digital audio, supporting high-fidelity audio up to 24-bits / 192 kHz. The Dante audio output can be sampled at 44.1 to 96 kHz, ensuring clear, professional-grade sound. With configurable Dante audio delay options of 1, 2, or 5 milliseconds, this adapter delivers precise timing and low-latency performance.
Bidirectional Conversion
Thanks to bidirectional communication across both the USB and RJ45 Dante connections, you can convert audio in either direction for maximum flexibility. The USB data connection provides up to 24-bit bit depth at up to a 192 kHz sampling rate for USB output, while USB input supports up to 96 kHz.
Built Tough for Professionals
The Dante Pro adapters are housed in an all-metal chassis for maximum ruggedness. Painted in a distinct Turtle Aqua finish, this adapter looks great and is easily identified by users for its status as a pro adapter in your setup.
Uncompromising Dante Technology
In networked audio, precision is essential, and Dante by Audinate delivers with tight synchronization and ultralow-latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by a genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless professional-grade sound for all installations, from live performances to intricate broadcast environments.
Easy Software-Based Control
Take command with Dante Controller. Turtle AV adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle. This adapter supports Dante Domain Manager and all other Dante software applications.
Sustainable and Earth-Friendly Design
Crafted with a commitment to sustainability, this adapter is made from 90% recycled plastic, including 5% ocean-bound plastic. The materials have been carefully selected to ensure there is no compromise to the ruggedness or durability. The packaging contains no plastics or petrochemicals, and the box is made from 100% recycled cardboard and p
SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Input/Output Interconverts between two-channel USB audio and Dante® 2CH digital audio
USB Audio Class 1.0/2.0-compatible
USB Audio Input Up to 96KHz @ 24bit
USB Audio Output Up to 192KHz @ 24bit
Control Dante® Controller
NETWORK
Bandwidth 100M
Audio Latency Configurable Dante® device latency (Supports 1, 2, or 5ms configurable using Dante® Controller)
AUDIO FORMATS
USB IN Digital audio input, PCM 2CH, 44.1K-96KHz, 16/24bit
USB AUDIO OUT Digital audio output, PCM 2CH, 44.1K-192KHz, 16/24bit
DANTE IN/OUT Digital audio output, PCM 2CH, 44.1K-96KHz, 16/24bit
AUDIO PARAMETERS
USB IN
Frequency Response 20Hz to 20kHz (-/+0.5dB)
Dynamic Range >100dB @ 0dBu, 1kHz, A-weighted
Audio S/N Ratio >100dB @ 0dBu, 1kHz, A-weighted
Audio THD+N <0.01% at +4dBu, 1kHz
Audio Output Sync Delay <10ms
ESD PROTECTION
Standard IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
CONNECTIONS
Input/Output 1x USB-C (USB 1.0/2.0, USB audio in/out, 12-pin female)
Power 1x POWER (2-pin phoenix, 3.81mm)
Network 1x DANTE (RJ45 LAN, PoE)
MECHANICAL SPECIFICATIONS
Housing Metal enclosure
Colour Turtle Aqua
Dimensions 120mm [W] x 47mm [D] x 26mm [H]
Weight 188g
POWER SUPPLY
PoE PoE IEEE802.3af Class 0
USB 5V/500mA
Power Consumption 2W (Max)
ENVIRONMENTAL
Operating Temperature 32 – 104°F / -20 – 60°C
Relative Humidity 20% – 90% RH (non-condensing)
