Description

Turtle AV JEF Dante Enabled Mic Preamp

FEATURES

  • Mic Preamp with 48V Phantom Power
  • Primary and Secondary Dante Networks
  • Dual PoE
  • Locking etherCON connectors
  • 8 Band Parametric EQ
  • Dante and AES67
  • Aircraft Grade Aluminium housing
  • Compressor & Expander
  • 5 filters including high pass and low pass
  • WebUI and API control
  • TAA compliant
  • 5-year warranty

Mic Preamp. Dante Networked Audio. Remote Control. Advanced Audio Processing.

JEF converts microphones directly to Dante with low noise mic preamps, onboard DSP, and full network and power redundancy. Remote microphone control. Simplified. Designed for boardrooms, stadiums, and broadcast environments, JEF integrates seamlessly into any Dante or AES67 workflow. Signal processing is handled onboard, reducing reliance on external DSP and simplifying system design.

TAA compliant and backed by a 5 year advance replacement warranty, JEF is built for long term deployment in professional AV and broadcast systems.

Mic Preamp. Remotely Controlled.
Precision preamps you can tweak from anywhere. Adjust your gain levels without ever leaving the mix position.

48V Phantom Power.

Regulated 48V phantom power for condenser microphones, delivering stable operation across long distances.

Primary and Secondary Dante Networks.

Build redundancy into your workflow with primary and secondary Dante networks, providing automatic failover for uninterrupted audio transport.

Dual PoE for power redundancy.

Supports power over Ethernet on both network ports, providing power redundancy when connected to separate PoE sources.

SPECIFICATIONS

Microphone Input
Balanced XLR Female
Maximum Input Level: 24 dBu
Phantom Power
+48 V
Input Sensitivity
0, -10, -20, -30, -40, -50 dBu
Sample Rate
44.1 to 96 kHz, 16/24 Bit
Frequency Response
20 Hz to 20 kHz (±:0.5 dB)
Dynamic Range
> 90 dB at 0 dBu, 1 kHz A-Weighted
S/N Ratio
> 90 dB at 0 dBu, 1 kHz A-Weighted
THD+N
< 0.01% at +4 dBu, 1 kHz
Network
Dante/AES67, PCM 2 Channels, 44.1 to 96 kHz, 16/24 Bit
Latency
< 1 ms
Dante
Dante Latency: 2, 3, 4, 5, or 10 ms
Dante Redundancy: Primary and Secondary Network Ports
Network Ports
2 x Locking RJ45 etherCON
PoE
IEEE 802.3af
Control Interface
WebUI, API
Environmental
Operating Temperature: 32 to 104° F / 0 to 40° C
Relative Humidity: 20 to 80% Relative Humidity, Non-Condensing
Dimensions
2.4 x 1.8 x 3.9" / 60 x 45 x 100 mm
