AJA UDC Up/Down/Cross-Converter - UDC-R0

The UDC is a broadcast quality Up/Down/Cross Mini-Converter which can convert between 3G, HD, and SD video formats. Using the same AJA industry-leading conversion technology as in our FS2, the UDC provides very high-quality conversions at a low price. I/Os include 3G/HD/SD SDI input and output, HDMI output, and 2-channel RCA style audio output. The UDC can be controlled by local DIP switches with additional control available via USB and AJA's MiniConfig application. A Reference input allows the UDC to be locked to a local reference.

FEATURES
Up, Down, Cross conversion between 3G, HD and SD video formats
Loss of input management: Freeze, Black, or Mute
Simultaneous SDI and HDMI outputs
16-channel embedded SDI audio input
16-channel embedded SDI audio output
8-channel HDMI audio output
2 RCA-style analogue outputs at -10dBV (nominal)
Genlock: Reference Input, SDI Input, or Free Run
Configure via DIP switch or USB port and supplied AJA Mini-Config software on PC/Mac
Uses 5-20 VDC power (DWP-U-R1 universal power supply included)
Five-year warranty
NOTE:
UDC supports 3G-SDI Level A only. 3G-SDI Level B is not supported.
UDC passes-through embedded audio ancillary data only. It does not pass through other types of embedded ancillary data.

SPECIFICATIONS

Video Formats

(HD) 1920 x 1080p
(HD) 1920 x 1080PsF
(HD) 1920 x 1080i
(HD) 1280 x 720p
(SD) 720 x 625i
(SD) 720 x 576i
(SD) 720 x 480i

Video Input Digital

1x 3G-SDI BNC, SMPTE-259/292/372/424
(HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
(HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30
(HD) 1920 x 1080i 50, 59.94, 60
(HD) 1280 x 720p 50, 59.94, 60
(SD) 720x576i 50, 59.94, 60

Video Output Digital

1x 3G-SDI BNC, SMPTE-259/292/372/424
- (HD) 1080p 23.98 (for 23.98 video inputs)
- (HD) 1080p 24 (for 24 video inputs)
- (HD) 1080p 25 (for 50 video inputs)
- (HD) 1080p 29.97 (for 59.94 video inputs)
- (HD) 1080p 30 (for 60 video inputs)
- (HD) 1080p 50 (for 50 video inputs)
- (HD) 1080p 59.94 (for 23.98, 59.94 video inputs)
- (HD) 1080p 60 (for 24, 30 or 60 video inputs)
- (HD) 1080PsF 23.98 (for 23.98 video inputs)
- (HD) 1080PsF 24 (for 24 video inputs)
- (HD) 1080PsF 25 (for 50 video inputs)
- (HD) 1080PsF 29.97 (for 59.94 video inputs)
- (HD) 1080PsF 30 (for 30 or 60 video inputs)
- (HD) 1080i 59.94 (for 23.98, or 59.94 video inputs)
- (HD) 1080i 60 (for 24, 30, or 60 video inputs)
- (HD) 1080i 50 (for 25 or 50 video inputs)
- (HD) 720p 50 (for 50 video inputs)
- (HD) 720p 59.94 (for 23.98, 59.94 video inputs)
- (HD) 720p 60 (for 24, 30, or 60 video inputs)
- (SD) 625i 50 (for 25 or 50 fps video inputs)
- (SD) 525i 59.94 (for 23.98 or 59.94 video inputs)

Reference Source

Free Run
Ext Ref

Reference Input

Supported reference video inputs include
- 1080i tri-level sync
- 1080p tri-level sync
- 720p tri-level sync
- 625i Color Black
- 525i Color Black
75-ohm terminating

HDMI Output

10-bit HDMI v1.4a

Audio I/O

16-channel embedded SDI audio input
16-channel embedded SDI audio output
8-channel HDMI audio output
2x RCA style analog outputs at -10 dBu (nominal)

Ancillary Data

Supports pass-through of PCM embedded audio
Supports pass-through of non-PCM audio when source is in time with the selected ref (SDI In or Ext Ref). Non-PCM audio is not supported during frame sync operation.
All other ANC data is stripped

HDCP

The UDC does not encode the HDMI output with HDCP encryption. By definition, HD-SDI inputs to the UDC are unencrypted. The HDMI specification requires HDMI monitors to support unencrypted inputs.

User Interface

USB port used with supplied cable and Mini-Config software application to configure device via PC or Mac

Size (w x d x h)

5.8" x 3.1" x 1.0" (147.32 x 78.74 x 25.4 mm)

Power

+5VDC Regulated, 7.0 Watts, Power Supply Required (included with purchase)

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)
Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
Operating Relative Humidity: 10-90% noncondensing
Operating Altitude: <3,000 meters (<10,000 feet)
