Sennheiser MKH 8030 Figure-8 RF Condenser Microphone - 700251

Available date: 01/03/2025

RF Condenser Microphone Set. Includes (1) 1x MKH 8030 Microphone, (1) MZW 8030 Foam Windshield, (1) MZQ 8000 Mic clamp (1) MZX 8000 XLR Module and (2) Rycote Back-to-Back clip

FEATURES

Broadcast, Orchestra, M/S Recording
Figure-8 Pickup Pattern
For MZX 8000 XLR/MZD 8000 Digital Module
Metal Housing, Non-Reflective Coating

Bi-directional figure-8 polar pattern captures sound equally from front and rear while efficiently rejecting sound from the side
Highly symmetrical and frequency-independent pick-up pattern
Ideal choice for combining with a cardioid or super-cardioid mic to provide a MS-Stereo setting
Low-tension diaphragm and symmetrical, acoustically open push-pull transducer design keeps the sound flow as unrestricted and undistorted as possible
Extended bass response allows for capturing sound in its full frequency extent and gives more freedom for microphone positioning
Extended treble range (up to 50 kHz) captures sound in fine detail with precise transient response
German-engineered with durable metal housing and rugged construction for superior reliability
Moisture-resistant design ideal for use in humid, hot, and cold environments where other mics fail
Low self-noise for greater detail in audio; retains the softness of quiet sounds, increases dynamics, and more
Low non-linear distortion avoids adding new frequency spectrum thus keeping sonic clarity
Compact size for easy transport; visually unobtrusive in live shows or TV
Modular design allows for easy combination with various MKH 8000 accessories
Nextel® non-reflecting paint ensures no reflection from stage lights, keeping mic visually unobtrusive in live shows or TV

Awards

The MKH 8030 figure-8 RF condenser microphone is designed to cater to the needs of sound engineers, broadcasters, and field recordists. It offers flexibility in recording configurations, such as Mid-Side (stereo), close-miking (mono), and surround sound, all within its compact form factor and resistance in challenging weather conditions.

Sennheiser MKH 8030 Figure-8 Condenser Microphone

Perfect for studio sessions, orchestral recordings, fieldwork, and broadcast use, the Sennheiser MKH 8030 Figure-8 Condenser Microphone empowers audio professionals to capture stunningly clear sound across an extensive frequency range in almost any setting. This versatile mic is compatible with the MZX 8000 XLR module and the MZD 8000 digital module, making it an excellent choice for capturing ambient room tone, recording duets, or isolating sound sources with high attenuation.

Its figure-8 pickup pattern is ideal for various stereo recording techniques, including Mid/Side and Blumlein configurations. The package includes an MZW 8030 foam windshield and MZQ 8000 mic clip, as well as a pair of Rycote Back-to-Back microphone clips, perfect for pairing with the MKH 8040 or 8050 for sophisticated mid-side or stereo audio capture.

Robust Construction for Natural and Detailed Sound

Featuring a remarkable push-pull transducer and an innovative low-tension diaphragm, the unique design of the MKH 8030 delivers superior sensitivity, wide frequency response (30 Hz to 50 kHz), extremely low inherent self-noise, wide dynamics, extremely low distortion, and a frequency-independent figure-8 polar pattern that avoids colouration, so you can capture sound as authentically as possible.
A rugged metal housing with non-reflective Nextel coating offers high resistance to moisture.
The MKH 8030's sound signature has been carefully engineered to blend harmoniously with the sound of the existing MKH 8000 series microphones.

Modular Design

The modular design consists of the MKH 8030 figure-8 microphone and the MZX 8000 XLR preamp module with a fully floated, balanced output signal.
The MKH 8030 is also compatible with the MZD 8000 digital module.

Figure-8 Polar Pattern

High rejection of lateral sounds.
Use for Mid/Side and Blumlein stereo arrays.

SPECIFICATIONS

DimensionsØ 19 mm, L 59 mm (93 mm with MZX 8000)
Weight (g)38 g (70 g with MZX 8000)
Max. sound pressure level139 dB
Sensitivity-31 dBV/Pa (28 mV/Pa)

WHAT'S IN THE BOX

(1) MKH 8030 Microphone

(1) MZW 8030 Foam Windshield

(1) MZQ 8000 Mic clamp

(1) MZX 8000 XLR Module

(2) Rycote Back-to-Back clips

Safety instructions

Quick guide
