LILLIPUT Q31 31.5-inch 12G-SDI/HDMI Professional Broadcast Production Monitor

Lilliput Q31 is a professional production studio monitor, packed with features and facilities for the professional photographer, videographer, or cinematographer. Compatible with a multitude of inputs – and featuring the option of a 12G SDI and 12G-SFP Fiber Optic input connection for broadcast quality monitoring, It also features Audio Vectoring using a Lissajous graph shape allowing you to visualize the depth and balance of a stereo recording. You also can connect your computer to control the monitor via applications.

FEATURES

31.5" 3840 x 2160 Resolution Monitor

Supports up to DCI 4K Input

Supports Accurate Color Calibration

HDR Support, Load Custom 3D LUTs

178° H/V Viewing Angle

350 cd/m² Brightness

1300:1 Contrast Ratio

On-Screen Markers, Focus Peaking

XLR 4-Pin 12-24 VDC Power Input

HDR and 3D LUTs

When HDR is activated, the display reproduces a greater dynamic range of luminosity, allowing for colours and lighter and darker details to be displayed more clearly. You can use preset Logs or load your own custom LUTs in .cube format via the front panel USB port.

Supported Log Formats

SLog2. SLog3, CLog, NLog, ARRILiog, JLog, and User.

Supported HDR

ST2084 300/1000/10000/HLG.

Audio

The monitor can display the Lissajous shape, most useful when used in audio post-production work for detecting phase variance.

Assignable Buttons

Using the four assignable buttons on the front panel, you can quickly turn any four essential monitoring tools on and off without venturing into the monitor's menu system.

Remote Control

The monitor supports RS-422 via discrete in and out RJ45 connectors. This allows you to control the monitor from computer applications, as well as link multiple monitors together.

Calibration

The monitor supports colour calibration using an optional PRO/LTE version of LightSpace CMS, to ensure your monitor is displaying your image accurately.

Fibre

An integrated slot accepts an optional SFP+ module, should you require an SFP+ fibre connection.

Monitoring Tools

Peaking

Check field

Image rotation/flip

Overscan

Underscan

Image freeze

Pixel-to-pixel

False colour

Exposure

Histogram

Timecode (SDI-only)

Aspect ratio selection

Screen markers

Colour space

HDR

Colour temperature adjustment

The 12G SDI inputs allow the units allow for multiple configurations of input. Single Link, Dual Link, and Quad link inputs mean you can use a either a single input or conjoined inputs to make up your 4K video input signal. This opens up the input workflow for the multiple types of camera to be attached into the monitor depending on the usage and configuration of the video capture environment.

Audio Vectoring - The Lilliput Q31 allows for the visualization of the input audio using a Lissajous graph system. A graph is represented on screen, with two intersecting lines forming a cross. The line from top left to bottom right measures the left hand part of the stereo field, while to line from top right to bottom left measures the right hand part of the stereo field. The crossover of the two lines is the centre balance, and the audio field will create a specific shape in the graph to represent your input audio.

The optional 12G-SFP module allows for the receiving of broadcast quality transmission level video data over a fiber optic connection. Used by a great many TV broadcasters, Fiber-optic input is a the industry standard in control room video transfer technology.

With HDR activated (HDR 10), the display produces a much greater dynamic range of luminosity, allowing lighter and darker details to be displayed more clearly - effectively enhancing the overall picture quality.

Audio In / Out (48 kHz PCM Audio)
Built In Speakers	2x
Ear Jack	3.5mm
Display
Aspect Ratio	16:9
Brightness	350cdm²
Contrast Ratio	1300:1
Resolution	3840 x 2160
Technology	Calibration to REC.709 with optional calibration unit
Viewing Angle	178° / 178° (H/V)
HDR	ST2084 - 300/ 1000/10000/HLG
LUT Support	3D LUT (.cube format)
Screen Size	31.5"
Supported Log Formats	SLog2 / SLog3 / CLog / NLog / Arrilog / JLog / User
Remote Control
GPI	1
LAN	1
Supported Formats
HDMI Formats Supported	2160p - 24/25/30/50/60, 1080p - 24/25/30/50/60, 1080i,50/60, 720p 50/60
SDI Formats Supported	2160p - 24/25/30/50/60, 1080p - 24/25/30/50/60, 1080pSF - 24/25/30, 1080i,50/60, 720p 50/60
SFP Formats Supported	2160p - 24/25/30/50/60, 1080p - 24/25/30/50/60, 1080pSF - 24/25/30, 1080i,50/60, 720p 50/60
Video Loop Output
HDMI Video Loop Output	1x HDMI 2.0
SDI Video Loop	2x12G, 2x3G (Supported 4K-SDI Formats Single / Dual / Quad Link)
Connections
HDMI Video Input	1x HDMI 2.0
SFP	1x 12G SFP+ (Fiber module optional)
SDI Video Input	2x12G, 2x3G (Supported 4K-SDI Formats Single / Dual / Quad Link)
Size
Dimensions	567 x 377 x 46mm
Weight	7.4Kg
Power
Battery	V-Lock or Anton Bauer Compatible (Battery not included - requires 14.8V)
Input Voltage	DC 12-24V
Power Consumption	=< 32.5W (15v)
Environment
Operating Temperature	0°c - 40°c
Storage Temperature	-20°c - 60°c
